ATC Power Cables

ATC Power Cables with XLPE Insulation

Power cables with ISI mark as per IS 7098:1988, which covers Crosslinked Polyethylene (XLPE) Insulated PVC Sheathed Cables for working voltages up to and including 1100 volts:

Scope:

  • The standard applies to both armoured and unarmoured single, twin, three, four, and multi-core cables.
  • These cables are designed for electric supply and control purposes.

Construction:

  • Insulation: The cables feature crosslinked polyethylene (XLPE) insulation, which enhances their durability and electrical properties.
  • Sheath: The outer sheath is made of PVC (polyvinyl chloride), providing additional protection.

Features of XLPE-Insulated Cables:

  • High Thermal Resistance: XLPE does not melt like thermoplastics and remains thermally resistant even at elevated temperatures (up to 120°C for longer periods and up to 250°C for short durations without mechanical or electrical load).
  • Enhanced Properties: Compared to ordinary polyethylene (PE), XLPE offers significantly improved properties.
  • Dielectric Excellence: XLPE has excellent dielectric properties, making it suitable for medium and high-voltage cables (up to 380 kV AC and several hundred kV DC).
  • Rated Maximum Conductor Temperature: XLPE-insulated cables have a rated maximum conductor temperature of 90°C and an emergency rating up to 140°C, depending on the standard used.
  • Shear Modulus: Increasing crosslinking density enhances the shear modulus, especially in high- voltage cable applications.

Advantages of XLPE Insulation:

  • Cost Efficiency: XLPE insulation provides cost-effective operation and procurement compared to older impregnated paper systems.
  • Environmental Friendliness: It has lower environmental and maintenance requirements.
  • Wide Application Range: Used in power transmission, distribution, and other critical systems.
  • Quality assurance: All cables are ISI marks with BIS standards ISI:1554 (Part-1) 1988, ISI:7098/1990, ISI:14255 (Part-1)

Applications of XLPE-Insulated Cables:

  • Power Transmission and Distribution: XLPE cables are widely used for power transmission and distribution purposes.
  • High Voltage Electrical Cables: XLPE serves as insulation for high-tension electrical cables.
  • HVAC Industry: Used on copper pipes, MS pipes, drainpipes, chilled water pipelines, AC ducts, and air handling units.

ATC (which stands for Advanced Technology Cables) is synonymous with quality, safety, and reliability. Just as a well-insulated cable ensures longevity and efficiency, ATC’s commitment to excellence ensures that your buildings are constructed with the utmost care and durability. Whether it’s a warehouse, office, school, or factory, ATC’s cables contribute to the robustness and longevity of your projects.
